Kohler 6kW - Marine Diesel Generator 6EKOD, 12v, 60Hz, 1 PH without Sound Shield

Kohler 6kW - Marine Diesel Generator 6EKOD, 12v, 60Hz, 1 PH without Sound Shield
Kohler 6kW - Marine Diesel Generator 6EKOD, 12v, 60Hz, 1 PH without Sound Shield
Kohler 6kW - Marine Diesel Generator 6EKOD, 12v, 60Hz, 1 PH without Sound Shield
Kohler 6kW - Marine Diesel Generator 6EKOD, 12v, 60Hz, 1 PH without Sound Shield
20% OFF
BEST SELLER
SALE
Kohler 6kW - Marine Diesel Generator 6EKOD, 12v, 60Hz, 1 PH without Sound Shield
Kohler 6kW - Marine Diesel Generator 6EKOD, 12v, 60Hz, 1 PH without Sound Shield
Kohler 6kW - Marine Diesel Generator 6EKOD, 12v, 60Hz, 1 PH without Sound Shield
Kohler 6kW - Marine Diesel Generator 6EKOD, 12v, 60Hz, 1 PH without Sound Shield
$11,224.80
$14,031.00 Save $2,806.20
* DUE TO SIZE AND WEIGHT, ALL GENERATORS HAVE A SHIPPING FEE. AN MMARINE REPRESENTATIVE WILL BE HAPPY TO ASSIST YOU WITH A SHIPPING ESTIMATE PRIOR TO PURCHASE.
Low in stock
Pre-order
Discontinued
In stock
Out of stock
Notify me When Available
You will receive an email when the product is available.

Kohler 6kW - Marine Diesel Generator 6EKOD, 12v, 60Hz, 1 PH without Sound Shield

SKU 6EKOD
Product type Marine Generators
List price $14,031.00
Sale price
$11,224.80
Date Created 04 / 03 / 2024
Kohler 6kW - Marine Diesel Generator 6EKOD, 12v, 60Hz, 1 PH without Sound Shield

Product details

Kohlers 6EKOD Marine Diesel Generator is a great choice for any maritime application. This single-phase, 60Hz generator delivers reliable power output of up to 12v. With its robust construction and reliable performance, the 6EKOD is an ideal choice for powering your boat or yacht.



  • Frequency 60 Hz
  • kW 6
  • Controller ADC IId Advanced Digital Control
  • Fuel Type Diesel
  • Alternator Type 4-pole, rotating-field
  • Engine Manufacturer Kohler


Engine features:

  • Certified by the Environmental Protection Agency (EPA) to conform to Tier III marine auxiliary standards.
  • Closed cooling system
  • Heat exchanger
  • Oil drain valve
Generator features:
  • Remote start 12-pin connector
  • Voltage regulation of ±1.0%
  • Rotor and stator are coated with a high-bond epoxy varnish. Varnish helps prevent corrosion in high-humidity areas.
  • Copper windings ensure minimal heat buildup. Insulation meets NEMA standards for class H insulation.
  • Direct connected to the engine, the generator has sealed precision ball bearings with a precision-machined steel sleeve in the end bracket to prevent shaft misalignment and extend bearing life.



Engine Features

  • Diesel fueled
  • Certified by the Environmental Protection Agency (EPA) to conform to Tier III marine auxiliary standards
  • Three cylinder
  • Four cycle
  • Closed cooling system
  • Heat exchanger
  • Lifting eye

Generator Features

  • Remote start 12-pin connector
  • Class H insulation
  • Multivoltage adjustability
  • Voltage regulation of 1.0%
  • Radio suppression

ADC IId Advanced Digital Control Features

  • Designed for today’s most sophisticated electronics
  • Easy to read 12 x 2 LCD alpha-numeric display
  • Compact, integrally mounted control
  • Sealed connectors for maximum corrosion protection
  • SAE J1939, SmartCraftt, NMEA 2000 selectable CANbus outputs
  • Remote monitoring of fault conditions
  • Push button dial for configuration and adjustment
  • Programmed crank cycle

Product details

Kohlers 6EKOD Marine Diesel Generator is a great choice for any maritime application. This single-phase, 60Hz generator delivers reliable power output of up to 12v. With its robust construction and reliable performance, the 6EKOD is an ideal choice for powering your boat or yacht.



  • Frequency 60 Hz
  • kW 6
  • Controller ADC IId Advanced Digital Control
  • Fuel Type Diesel
  • Alternator Type 4-pole, rotating-field
  • Engine Manufacturer Kohler


Engine features:

  • Certified by the Environmental Protection Agency (EPA) to conform to Tier III marine auxiliary standards.
  • Closed cooling system
  • Heat exchanger
  • Oil drain valve
Generator features:
  • Remote start 12-pin connector
  • Voltage regulation of ±1.0%
  • Rotor and stator are coated with a high-bond epoxy varnish. Varnish helps prevent corrosion in high-humidity areas.
  • Copper windings ensure minimal heat buildup. Insulation meets NEMA standards for class H insulation.
  • Direct connected to the engine, the generator has sealed precision ball bearings with a precision-machined steel sleeve in the end bracket to prevent shaft misalignment and extend bearing life.



Technical Specification

Engine Features

  • Diesel fueled
  • Certified by the Environmental Protection Agency (EPA) to conform to Tier III marine auxiliary standards
  • Three cylinder
  • Four cycle
  • Closed cooling system
  • Heat exchanger
  • Lifting eye

Generator Features

  • Remote start 12-pin connector
  • Class H insulation
  • Multivoltage adjustability
  • Voltage regulation of 1.0%
  • Radio suppression

ADC IId Advanced Digital Control Features

  • Designed for today’s most sophisticated electronics
  • Easy to read 12 x 2 LCD alpha-numeric display
  • Compact, integrally mounted control
  • Sealed connectors for maximum corrosion protection
  • SAE J1939, SmartCraftt, NMEA 2000 selectable CANbus outputs
  • Remote monitoring of fault conditions
  • Push button dial for configuration and adjustment
  • Programmed crank cycle

Dimensional Drawing

Dimensional Drawing
Generator without sound shield

Width: 448 mm (17.65 in.)

Height: 536 mm (21.12 in.)

Length: 743 mm (29.26 in.)

Weight, dry: 181 kg (398 lbs)

Weight, wet: 185 kg (407 lbs)
