Quick E3 1012D Windlass Gypsy & Drum (1000W / 12V / 6mm)

Quick E3 1012D Windlass Gypsy & Drum (1000W / 12V / 6mm)
Quick E3 1012D Windlass Gypsy & Drum (1000W / 12V / 6mm)
Quick E3 1012D Windlass Gypsy & Drum (1000W / 12V / 6mm)
15% OFF
Quick E3 1012D Windlass Gypsy & Drum (1000W / 12V / 6mm)
Quick E3 1012D Windlass Gypsy & Drum (1000W / 12V / 6mm)
Quick E3 1012D Windlass Gypsy & Drum (1000W / 12V / 6mm)
SKU: FSE01012D006A00
$3,604.43
$4,240.50 Save $636.07

🚚 FREE SHIPPING INCLUDED 🚚

Low in stock
Pre-order
Discontinued
In stock
Out of stock
Notify me When Available
You will receive an email when the product is available.

Quick E3 1012D Windlass Gypsy & Drum (1000W / 12V / 6mm)

SKU FSE01012D006A00
Product type Windlass
List price $4,240.50
Sale price
$3,604.43
Date Created 18 / 07 / 2024
Quick E3 1012D Windlass Gypsy & Drum (1000W / 12V / 6mm)

Product details

The Quick E3 Eagle 1012D windlass is suitable for boats from 10m to 13m (33 to 43ft). The horizontal axe windlass is quick and easy to install with a vertical motor and an Aluminium base, making it well protected and durable. Supplied with an Aluminium handle control and a built-in manual free-fall system, anchoring has never been easier. The Quick windlass features a 6mm gypsy on the right side, which is suitable for 6mm DIN766 and 6mm ISO chain. The Eagle 1012D also features a drum on the left side.

Key Features
  • Horizontal windlass
  • Base in anodized aluminium in hard oxide
  • With drum
  • Integrated sensor and magnet for chain counter
  • Manual Free-Fall system
  • IP66 watertight motor
Gypsy Size 6mm
Primary Construction Aluminium
Chain or Rope Chain
Boat Size 10 to 13 meters in length
Mounting [Filter] Horizontal Mount
Brand Quick
Series Eagle E3
Model 1012D
Voltage 12V DC
Wattage 1000W
Working Load 130kg (287 lb), Maximum: 390kg (860 lb)
Max Pull Load 1250kg (2756 lb)
Maximum Chain Speed 37.6 m/min (123.4 ft/min), At Working Load: 17.8 m/min (58.4 ft/min)
Amps 140A at 130kg
Fuse 80A Protection Circuit Breaker
Contents Windlass, Handle, Contactor Unit, Bolts and Screws, Drill Template, User Manual
Approvals CE
Height Overall: 415mm (16-11/32"), Above Deck: 205mm (8-3/32"), Below Deck: 210mm (8-1/4")
Width 295mm (11-5/8")
Depth 239.4mm (9-27/64")
Thickness Deck: 25mm - 50mm (31/32" - 1-31/32")
Size Motor Cable: 35mm2 (AWG2)



Technical Manual

Product details

The Quick E3 Eagle 1012D windlass is suitable for boats from 10m to 13m (33 to 43ft). The horizontal axe windlass is quick and easy to install with a vertical motor and an Aluminium base, making it well protected and durable. Supplied with an Aluminium handle control and a built-in manual free-fall system, anchoring has never been easier. The Quick windlass features a 6mm gypsy on the right side, which is suitable for 6mm DIN766 and 6mm ISO chain. The Eagle 1012D also features a drum on the left side.

Key Features
  • Horizontal windlass
  • Base in anodized aluminium in hard oxide
  • With drum
  • Integrated sensor and magnet for chain counter
  • Manual Free-Fall system
  • IP66 watertight motor
Gypsy Size 6mm
Primary Construction Aluminium
Chain or Rope Chain
Boat Size 10 to 13 meters in length
Mounting [Filter] Horizontal Mount
Brand Quick
Series Eagle E3
Model 1012D
Voltage 12V DC
Wattage 1000W
Working Load 130kg (287 lb), Maximum: 390kg (860 lb)
Max Pull Load 1250kg (2756 lb)
Maximum Chain Speed 37.6 m/min (123.4 ft/min), At Working Load: 17.8 m/min (58.4 ft/min)
Amps 140A at 130kg
Fuse 80A Protection Circuit Breaker
Contents Windlass, Handle, Contactor Unit, Bolts and Screws, Drill Template, User Manual
Approvals CE
Height Overall: 415mm (16-11/32"), Above Deck: 205mm (8-3/32"), Below Deck: 210mm (8-1/4")
Width 295mm (11-5/8")
Depth 239.4mm (9-27/64")
Thickness Deck: 25mm - 50mm (31/32" - 1-31/32")
Size Motor Cable: 35mm2 (AWG2)



Technical Manual
